DC 50V 100V 5A 10A Digital Voltmeter Ammeter Wattmeter Power Current Voltage Meter 250W 1000W High Power Volt Detector Tester

Electrical Instruments>>>Tools

Brand Name Aideepen

Origin CN(Origin)

DIY Supplies ELECTRICAL

Certification CE

Display Type Digital Only

Dimensions 79.5 x 43 mm

Model Number Digital Voltmeter Ammeter

Operating Temperature -10 to + 60 Celsius

Accuracy Class 1%

Supply Voltage DC 7-12V

DC 12V 50V 5A DC 100V 10A

Digital Voltmeter Ammeter Wattmeter Voltage Current Power Meter

Volt Detector Tester Monitor 250W 1000W

Color

Description:

Simultaneous display of voltage and current

Voltage Measurement Range DC 0-50V/0-100V

Current Measurement Range 0-5A/0-10A

Power Measurement Range 0-250W/0-1000W

Voltage Error Range ±1%(Adjustable)

Current Error Range ±1%(Adjustable)

Power Error Range ±1%(Adjustable)

Refresh Rate 300ms/Times

Display Method HTN LCD 3 Rows of 3 Digits

Customized or not YES

Supply Voltage DC 7-12V

Working Current <15mA

Working Temperature -10-60°

Package Include:

1PC x Digital Voltmeter Ammeter Wattmeter Power Current Voltage MeterDescription:Technical ParametersDisplay: 0.28" LED numberWorking voltage: DC 8~24VMeasuring voltage: DC 0.000~100.0VMeasuring current: DC 0.000~9.999AMeasuring power: DC 0.000W~1000WRefresh rate: ≥300ms/timeMeasurement accuracy: 1% (±1 bit)Working current: <30mAWorking temperature: -10 to 65 ° COperating humidity: 10 to 80% (non-condensing)Product size: 79.3mmx42.25x 24.38mmMounting hole: 72.0mm x 39.0mm
