Fans & Cooling>>>Computer & Office
Brand Name ALSEYE
Certification CE
Certification FCC
Certification RoHS
Origin CN(Origin)
Application Computer Case
Package Yes
Compatible CPU Yes
Power 5.1 W
Bearing Fluid Bearing
Fan Life 40000 hrs
Fan Speed Control 1200RPM
Noise 26dBA
Feature RGB Support
Air Volume 42.5CFM
Lines 5 Lines
Type Fan
Power Interface 4pin
Model Number X12
Heatsink Material plastic
Fan Size 120x120x25mm
PWM Suport Yes
PWM Speed 800/1000/1200 RPM
RGB Support Ausu/Gigabyte/Msi
RGB Control Type Remote or Motherboard (Can not at same time)
Blade Color
ALSEYE
Original Framless Design
Custom Fan Blades. High Airflow, Low Noise
X12 unique blade design for uses with high airflow and strong static pressure, use as case fan and ALSEYE XTREME series CPU liquid coolers, the airflow more concentrated.
Unique Frameless Design
Break the conventional framed design to reduce loss of wind and increase airflow.
Extreme Cooling Performance
High performance 4-phase motor, anti-aging, long life.
Get Know Thoroughly
Always pursuing a design that is not redundant to get better performance. We are constantly changing, bringing a comfortable user experience.
Constantly polished, good quality
The appearance of the X12 is the direction we are constantly pursuing. Samples have been repeadedly modified and proofed through long-term research by our team, ID designers, structural engineers and electronics egineeres.
X12 installation diagram
Fan Spesifications
Fan dimensions ----------- 120 x 120 x 30mmWeight --------------------- 95 +/-5gColtage --------------------- DC 12VCurrent ---------------------- 0.65A +/- 10%Fan Speed ------------------ 800/1000/1200RPM +/-10%Max.Airflow ---------------- 42.2CFM +/-10%Noice Level ----------------- 26.3dB(A) +/-10%Bearing Type --------------- HydraulicKife Expectancy ------------ 40,000hours
Controller(Hub) Specifications
Dimension ---------------------- 83 x 53 x 18mmFan Connector ------------------ 7pcsRGB Strip Connector ----------- 2pcsMainboard Connector --------- 1pcsWorking Temperature --------- -20℃ ~ 60℃Effective Rometo Distance ---- 8M
Remote Specification
